UL3140 300V 150C Tinned Copper Silicone Rubber Heater Wire for Appliances
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Conductor Material | Tinner Copper | Diameter | 20 AWG, 22 AWG, 24 AWG, 26AWG |
|---|---|---|---|
| Insulation Material | Silicone Rubber | Rated Voltage | 300 V |
| Conductor Type | Stranded | Temperature Rating | 150C |
| Insulation Thickness | 1.60 Mm | Max Conductor Resistance | 150 Ω/KM (26AWG), 94.2 Ω/KM (24AWG), 59.4 Ω/KM (22AWG), 36.7 Ω/KM (20AWG) |
| Unit Length | 305 Meter/roll | Conductor Diameter | 0.40 Mm (26AWG), 0.50 Mm (24AWG), 0.65 Mm (22AWG), 0.81 Mm (20AWG) |
| Insulation Diameter | 3.60 Mm (26AWG), 3.70 Mm (24AWG), 3.85 Mm (22AWG), 4.01 Mm (20AWG) | UL Standard | UL3140 |
| Strand Construction | 1/0.40 Mm (26AWG), 1/0.50 Mm (24AWG), 1/0.65 Mm (22AWG), 1/0.81 Mm (20AWG) | Color Options | Accept Customized |
| Conductor Resistance | 150 Ω/KM (26AWG) | ||
| Highlight | 300V Rated Voltage Silicone Rubber Heater Wire,150C Temperature Rating Silicone Rubber Insulated Wire,Tinned Copper Conductor UL3140 Wire |
||
Product Description
UL3140 300V 150°C Tinned Copper Silicone Rubber Heater Wire
Available in 20AWG, 22AWG, 24AWG, and 26AWG configurations for various heating applications.
Seeking Country Agents for a Win-Win Partnership
Product Overview
Technical Specifications
| Conductor | Construction (No./mm) | Diameter (mm) | Insulation Nominal Thickness (mm) | Diameter (mm) | Max. Conductor Resistance (Ω/KM) | Unit Length (M/Ft) |
|---|---|---|---|---|---|---|
| 26 AWG | 1/0.40 | 0.40 | 1.60 | 3.60 | 150 | 305/1000 |
| 24 AWG | 1/0.50 | 0.50 | 1.60 | 3.70 | 94.2 | 305/1000 |
| 22 AWG | 1/0.65 | 0.65 | 1.60 | 3.85 | 59.4 | 305/1000 |
| 20 AWG | 1/0.81 | 0.81 | 1.60 | 4.01 | 36.7 | 305/1000 |
Click contact us for a competitive quote
Company Profile
Our Products
Applications
Our Overseas Clients
Exhibition Participation
Certifications
Frequently Asked Questions
- Who Are We? Professional manufacturer of high-temperature wires and cables with 26 years of experience. Headquartered in Shenzhen, Guangdong, China with production bases in Dongguan and Jingzhou.
- What Can We Provide? High-temperature wires and cables, silicone tubing including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, and wiring harnesses.
- Why Choose Us? Free samples, competitive pricing, high quality standards, and customized services.
- What Certifications Do We Have? UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC certification.
- What Services Can We Provide? Accepted delivery terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted payment currency: USD, EUR, CNY. Accepted payment type: T/T, L/C, PayPal, Western Union, Cash.
