UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones

  • UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
  • UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
  • UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
  • UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
  • UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
  • UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones
Place of Origin Guangdong, China
Brand Name MYSUN
Model Number UL1901
Minimum Order Quantity 3050

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Conductor Material Tinned Copper Diameter 10 AWG, 12 AWG, 14 AWG, 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG, 6 AWG, 8 AWG, 4 AWG, 2 AWG, 1 AWG, 26AWG, 7AWG, 5AWG, 3AWG, 0AWG, 2/0AWG, 3/0AWG, 4/0AWG
Insulation Material Rubber Rated Voltage 600 V
Conductor Type Solid Shape Round
Temperature Rating 200℃ Type Insulated
Unit Length 305/1000 Insulation Thickness 0.350 Mm, 0.500 Mm, 0.760 Mm
Max Conductor Resistance 381 Ω/KM, 239 Ω/KM, 150 Ω/KM, 94.2 Ω/KM, 59.4 Ω/KM, 36.7 Ω/KM, 23.2 Ω/KM, 14.6 Ω/KM, 8.96 Ω/KM, 5.64 Ω/KM, 3.55 Ω/KM, 2.23 Ω/KM, 1.77 Ω/KM, 1.41 Ω/KM, 1.12 Ω/KM, 0.89 Ω/KM, 0.71 Ω/KM, 0.56 Ω/KM, 0.4268 Ω/KM, 0.3367 Ω/KM, 0.267 Ω/KM, 0.2119 Ω/KM, 0.168 Ω/KM Conductor Construction 7/0.10, 7/0.12, 7/0.16, 7/0.20, 19/0.15, 19/0.19, 19/0.235, 19/0.30, 19/0.37, 19/0.47, 19/0.43, 37/0.54, 37/0.60, 37/0.68, 37/0.76, 37/0.86, 7/2.21, 7/2.48, 7/2.78, 7/3.20, 7/3.57, 7/3.94, 7/4.42
Nominal Diameter 0.30 Mm, 0.36 Mm, 0.48 Mm, 0.60 Mm, 0.75 Mm, 0.93 Mm, 1.17 Mm, 1.50 Mm, 1.85 Mm, 2.35 Mm, 3.00 Mm, 3.78 Mm, 4.20 Mm, 4.76 Mm, 5.32 Mm, 6.02 Mm, 6.63 Mm, 7.44 Mm, 8.34 Mm, 9.60 Mm, 10.71 Mm, 11.82 Mm, 13.26 Mm Insulation Diameter 1.00 Mm, 1.08 Mm, 1.18 Mm, 1.30 Mm, 1.45 Mm, 1.63 Mm, 1.87 Mm, 2.20 Mm, 2.55 Mm, 3.05 Mm, 3.70 Mm, 4.78 Mm, 5.20 Mm, 5.76 Mm, 6.32 Mm, 7.02 Mm, 7.63 Mm, 8.44 Mm, 9.86 Mm, 11.12 Mm, 12.23 Mm, 13.34 Mm, 14.78 Mm
Highlight

UL1901 FEP Wire

,

600V High Temperature Wire

,

200C Robot Cable
Leave a Message
Product Description
UL1901 FEP Wire AWG 600V 200°C High Temperature Wire for Robot Cable
Supplies Fortune 500 Companies - Top PFA Wire Supplier In China.
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 0 UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 1
Specification
UL1901 Conductor Insulation Max. Cond Resistance (Ω/KM) Unit length (M)(Ft)
Size (AWG) Construction (No.mm) Diameter (mm) Nominal thickness (mm) Diameter (mm)
307/0.100.300.3501.00381610/2000
287/0.120.360.3501.08239610/2000
267/0.160.480.3501.18150610/2000
247/0.200.600.3501.3094.2610/2000
2219/0.150.750.3501.4559.4305/1000
2019/0.190.930.3501.6336.7305/1000
1819/0.2351.170.3501.8723.2305/1000
1619/0.301.500.3502.2014.6305/1000
1419/0.371.850.3502.558.96305/1000
1219/0.472.350.3503.055.64305/1000
1019/0.433.000.3503.703.55305/1000
837/0.543.780.5004.782.23Customize
737/0.604.200.5005.201.77Customize
637/0.684.760.5005.761.41Customize
537/0.765.320.5006.321.12Customize
437/0.866.020.5007.020.89Customize
37/2.216.630.5007.630.71Customize
27/2.487.440.5008.440.56Customize
17/2.788.340.7609.860.4268Customize
07/3.209.600.76011.120.3367Customize
2/07/3.5710.710.76012.230.267Customize
3/07/3.9411.820.76013.340.2119Customize
4/07/4.4213.260.76014.780.168Customize
Click Contact us Get the Best Quote
Company Profile
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 2 UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 3
Our Products
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 4
Application
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 5
Our Overseas Clients
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 6
Exhibition
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 7
Certifications
UL1901 FEP Wire 600V 200C High Temperature Wire for Industrial Robots and Drones 8
FAQ
  • Who Are We? We are a professional manufacturer of high-temperature wires and cables with 26 years of electric wire experience. Our headquarter is located in Shenzhen, Guangdong, China, and our two production bases are located in Dongguan, Guangdong, China and Jingzhou, Hubei, China.
  • What Can We Provide? We can provide high-temperature wires and cables, silicone tubing - including silicone rubber wire, XLPE, FEP/PFA/ETFE/PTFE wire, new energy cable, wiring harnesses.
  • Why Choose Us? A. Free Sample. B. Competitive Price. C. High Quality Standard. D. Customized Service.
  • What Certifications Do We Have? We have UL, cUL, VDE, Reach, CE, ROHS, CCC, CQC Certification.
  • What Services Can We Provide? Accepted Delivery Terms: FOB, CIF, EXW, FAS, CIP, FCA, DDP, DDU. Accepted Payment Currency: USD, EUR, CNY. Accepted Payment Type: T/T, L/C, PayPal, Western Union, Cash.
