UL3135 12-26AWG 600V High Temperature Silicone Insulated Wire for Industrial and Home Appliance
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Conductor Material | Copper | Diameter | 16 AWG, 18 AWG, 20 AWG, 22 AWG, 24 AWG |
|---|---|---|---|
| Insulation Material | Rubber, Silicone Fiberglass Braiding Rubber | Rated Voltage | 600 V |
| Conductor Type | Stranded | Shape | Round |
| Temperature Rating | 200℃ | Conductor Construction | 7/0.16 To 50/0.254 |
| Insulation Thickness | 0.78 Mm | Max Conductor Resistance | 143 To 5.53 Ω/KM |
| Unit Length | 305/1000 M/Ft | Conductor Diameter | 0.48 To 2.63 Mm |
| Insulation Diameter | 2.04 To 3.92 Mm | Cross Section Area | 0.30mm² To 2.50mm² |
| Strand Count | 7 To 50 | ||
| Highlight | UL3135 Silicone Insulated Wire,12-26AWG High Temperature Wire,600V Silicone Rubber Wire |
||
Product Description
UL3135 12-26AWG 600V 200°C High Temperature Silicone Rubber Wire for Home Appliances
Product Description
Specifications
| Conductor Size (AWG) | Construction (No./mm) | Diameter (mm) | Insulation Thickness (mm) | Diameter (mm) | Max. Conductor Resistance (Ω/KM) | Unit Length (M/Ft) |
|---|---|---|---|---|---|---|
| 26 | 7/0.16 | 0.48 | 0.78 | 2.04 | 143 | 305/1000 |
| 24 | 7/0.20 | 0.61 | 0.78 | 2.17 | 89.3 | 305/1000 |
| 22 | 7/0.254 | 0.77 | 0.78 | 2.33 | 56.4 | 305/1000 |
| 20 | 7/0.31 | 0.94 | 0.78 | 2.5 | 35.2 | 305/1000 |
| 18 | 7/0.39 | 1.19 | 0.78 | 2.75 | 22.2 | 305/1000 |
| 16 | 7/0.49 | 1.49 | 0.78 | 3.05 | 14 | 305/1000 |
| 24 | 11/0.16 | 0.61 | 0.78 | 2.17 | 89.3 | 305/1000 |
| 22 | 17/0.16 | 0.76 | 0.78 | 2.32 | 56.4 | 305/1000 |
| 20 | 26/0.16 | 0.94 | 0.78 | 2.5 | 35.2 | 305/1000 |
| 18 | 41/0.16 | 1.18 | 0.78 | 2.74 | 22.2 | 305/1000 |
| 16 | 26/0.254 | 1.49 | 0.78 | 3.05 | 14 | 305/1000 |
| 14 | 41/0.254 | 1.87 | 0.78 | 3.43 | 8.78 | 305/1000 |
| 12 | 19/0.47 | 2.63 | 0.78 | 3.92 | 5.53 | 305/1000 |
Packaging
Applications
Frequently Asked Questions
How can I contact your company?
We are always ready to serve you via Email, Telephone, Fax, Skype, Whatsapp or Mobile.
What is your working time?
Monday-Saturday: 7:30AM-17:00PM (Beijing time, GMT+08.00). We have public holidays during May 1-3, Oct 1-7 and Chinese New Year. Please email us during our holidays if you have any questions.
Do you provide free samples?
Yes, we can provide a free sample for testing. The buyer should bear all shipping costs.
What are your payment terms?
T/T, L/C, D/A, D/P, Western Union, MoneyGram, Paypal.
What is the lead time?
Usually sample lead time is 7 days after payment has been confirmed.
