XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red

  • XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red
  • XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red
  • XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red
  • XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red
Place of Origin Guangdong ,China
Brand Name MYSUN
Certification UL
Model Number UL3271
Minimum Order Quantity 3050meters
Price 0.1-1.5USD/M
Packaging Details 305M/roll,610M/roll,carton 32cm*32cm*32cm
Delivery Time 5-10 working days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 500000 meters per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name UL3271 Insulation XLPE
Conductor Tinned Copper Rated Voltage 600V-750V
Rated Temperature 125°C Application Heating,UAV,robot,lighting
Standard UL758 Sizes 30-2AWG
OD 1.86-9.90mm Package 305m/roll,610m/roll
Usage Lighting
High Light

XLPE Insulation Lighting Hook Up Wire

,

Copper Conductor XLPE Hook Up Wire

,

XLPE Lead Tinned Hook Up Wire
Leave a Message
Product Description

Hook up cable UL3271 XLPE Insulation lighting Lead Tinned Copper Conductor red

UL3271 specification

  • Flexibility: XLPE insulation
  • Maximum conductor resistance: 381 ohm/km
  • Resistant to oil, hot and cold, flexing
  • Rated temperature: 125°C
  • Rated voltage: 600V-750V
  • Insulation potential strength: 2000 VAC/min
  • Passes the FT2 flame test
  • Available in 2AWG,4AWG,6AWG,8AWG,9AWG,10AWG,12AWG,14AWG,16AWG, 18 AWG, 20 AWG, 22 AWG,24AWg,26AWG,28AWG,30AWG



UL3271 demesion:



Conductor Insulation Max.Cond Resistance Unit length
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		 Nominal Thickness
(mm)		 Diameter
(mm)		 (Ω/KM) (M)(Ft)
30 7/0.10 0.30 0.78 1.86 381 610/2000
28 7/0.127 0.38 1.94 239
26 7/0.16 0.48 2.04 150
24 11/0.16 0.60 2.16 94.2
22 17/0.16 0.76 2.32 59.4
20 21/0.18 0.94 2.49 36.7
18 16/0.254 1.18 2.73 23.2
16 26/0.254 1.50 3.06 14.6
14 41/0.254 1.89 3.45 8.96
12 65/0.254 2.37 3.93 5.64
10 105/0.254 3.02 4.58 3.55
9 133/0.254 3.36 4.92 2.82
8 133/0.28 3.75 1.15 6.05 2.23 100/328
6 84/0.45 4.79 7.09 1.41
4 133/0.45 6.02 8.32 0.89
2 212/0.45 7.60 9.90 0.56








XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red 0

XLPE Insulation Lighting Hook Up Wire UL3271 Lead Tinned Copper Conductor Red 1

Service:
Shipment:
1. by express
2. by sea

Payment terms:
LC, TT, Western Union, Money Gram and PayPal

Delivery:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days

FQA

1. Are you a manufacturer?

A:Yes,Our factory is located in Dongguan City more than 20,000 sqmm;

and have 20 years leading experience in manufacturing wires.



2. What are your main products?

A:Our main products are SR wire,FEP wires ,xlpe pvc wires and Mica wires Wire Harnesses.



3.What certification did your products pass?

A: We attained UL; cUL, CSA;VDE; CCC;IATF 16949;ISO 9001;ISO 14001 ROHS,REACH certifications
