VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08

Place of Origin Guangdong,China
Brand Name Mysun
Certification UL/cUL/CCC/CE/RoHS/SGS
Model Number UL3302
Minimum Order Quantity 3050meters
Price 0.06~0.48USD per M
Packaging Details Standard packge: cardboard box Accept custom-made.
Delivery Time 7-15 working day
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 500000 Meters per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Conductor Type Stranded Color Black
Usage Widely Used In Home Appliance ,lighting ,heater,motor & Generator,UAU,robot,industrial Power Etc Rated Voltage 30v
Rated Temperature 80 C Size 32AWG
Conductor Copper Certification ROHS/CCC/VDE/CCC/ISO9001:2008
Standard UL758 Insulation XLPE
Type Insulated Max.Cond Resistance 563 Ω/KM
Construction 7/0.10 Unit Length 1200/4000
High Light

VDE XLPE Insulation Copper Wires

,

UL758 XLPE Insulation Copper Wires

,

32AWG XLPE Hook Up Cable

Leave a Message
Product Description

UL Standard 32AWG 7/0.08 Wires and Cables XLPE Insulation Copper Wires



UL 3302 Specifications:

Nominal voltage:30V

Temperature range:105℃

Standard: UL3302

Insulation: xlpe

Conductor:  copper



Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.







Product Parameter



Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.


Conductor Insulation Max.Cond Resistance (Ω/KM) Unit length (M)(Ft)
Size
(AWG)
Construction
(No./mm)
Diameter
(mm)
Nominal Thickness
(mm)
Diameter
(mm)
40 7/0.03 0.09 0.13 0.35 3756 1220/4000
38 7/0.04 0.12 0.38 2254
36 7/0.05 0.15 0.41 1443
34 7/0.06 0.18 0.44 908
32 7/0.08 0.24 0.50 563
30 7/0.10 0.30 0.56 381
28 7/0.127 0.38 0.64 239
26 7/0.18 0.5 0.25 1.00 150



Our Product



VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08 0



Product Description



VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08 1

VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08 2



Package & Delivery



Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days



VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08 3







Company Introduction



VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08 4

VDE UL758 XLPE Insulation Copper Wires UL 32AWG 7/0.08 5
