High Temperature Electrical Wire Insulation Flexible AWM Cable UL 758 Standard
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Certification | ROHS/UL/CCC/VDE/CCC/SGS/ISO9001:2008 | Rated Voltage | 300V |
|---|---|---|---|
| Rated Temperature | 150℃ | Conductor | Tinned Copper |
| Insulation | Silicone Rubber | Application | Home Appliance, Headlamp, Industrial Machine, Electro Thermal Products. |
| Color | Customized | Size | 2-8awg |
| Name | Lead Wire, Hook Up Wire, Heating Wire | Flame Test | FT-2 |
| High Light | heat resistant electrical cable,high temperature heater wire |
||
Product Description
flexible UL 3213 Silicone Rubber Insulated Wire tinned copper wire
specifications
| Retad voltage | 300V |
| Retad temperature | 150°C |
| Insulation | silicone rubber |
| Conductor | tinned copper wire |
| Standards | UL 758 |
| Application | home appliances/ leds/industrial machine |
| M/FT | 305/1000 |
| Color | white,black,red,brown,yellow,blue,green,transparent etc. |
product dimensions
| Conductor | Insulation | Max.Cond Resistance | Unit length | |||
| Size (AWG) | Construction (No./mm) | Diameter (mm) | Nominal Thickness (mm) | Diameter (mm) | (Ω/KM) | (M)(Ft) |
| 8 | 19/0.75 | 3.75 | 1.55 | 6.85 | 2.16 | 100/328 |
| 6 | 266/0.254 | 5.52 | 1.55 | 8.62 | 1.362 | 100/328 |
| 4 | 420/0.254 | 6.63 | 1.55 | 9.73 | 0.8559 | 100/328 |
| 2 | 655/0.254 | 8.75 | 1.55 | 11.85 | 0.5384 | 100/328 |
applications
Silicone insulated wires are used for a variety of industrial applications due to the above mentioned advantageous properties.
The below mentioned industrial applications make the best use of these insulated wires.
1.Internal Wiring of Home Appliances and Industrial Applications:
Silicone insulated wires are ideal for flexible applications, and is used for internal wiring of industrial heating appliances,
Silicone insulated wires are ideal for flexible applications, and is used for internal wiring of industrial heating appliances,
hot-rolling mills, textile machines, industrial ovens, etc.
2.High Voltage Cable Assemblies:
Today, many cable assembly manufacturers prefer using silicone cables over regular cheap cable assemblies.
Today, many cable assembly manufacturers prefer using silicone cables over regular cheap cable assemblies.
Additionally, these wires have a dielectric strength of 550vpm, high insulation resistance, and excellent dielectric constant of 3-3.5.
These characteristics make these wires good electrical insulators, and are ideal for high voltage cable assemblies as well.
3.RoHS Compliant Applications:
As silicone rubber is a non-toxic substance, it is ideal for RoHS compliant applications.
This is also the reason why silicone insulated wires are used in various medical applications.
Factors to Consider When Selecting Silicone High Voltage Wires
Radiators
Steel mills
Electric motors
Hot rolling mills
Cooking surfaces
Heating apparatus
Industrial converters
Ovens and ventilators
Household appliances
Metallurgical facilities
Civil and industrial plants
Lighting (halogen lamps, etc.)
High voltage electrical cabins and circuits
Steel mills
Electric motors
Hot rolling mills
Cooking surfaces
Heating apparatus
Industrial converters
Ovens and ventilators
Household appliances
Metallurgical facilities
Civil and industrial plants
Lighting (halogen lamps, etc.)
High voltage electrical cabins and circuits
Service:
Shipment:
1. by express
2. by sea
1. by express
2. by sea
Payment terms:
LC, TT, Western Union, Money Gram and PayPal
LC, TT, Western Union, Money Gram and PayPal
Delivery:
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days
Sample order: 1-3 working days
Big order: 5-10 working days
Customized order: 10-15 working days
FAQ
1. Are you a manufacturer?
A:Yes,Our factory is located in Dongguan City more than 20,000 sqmm;
and have 20 years leading experience in manufacturing wires.
2. What are your main products?
A:Our main products are SR wire,FEP wires ,xlpe pvc wires and Mica wires Wire Harnesses.
3.What certification did your products pass?
A: We attained UL; cUL, CSA;VDE; CCC;IATF 16949;ISO 9001;ISO 14001 ROHS,REACH certifications
