610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V

  • 610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V
Place of Origin Guangdong ,China
Brand Name MYSUN
Certification UL
Model Number UL1569
Minimum Order Quantity 1000M
Price USD 0.02-0.8/M
Packaging Details 305M/roll,610M/roll
Delivery Time 5-10 working days
Payment Terms T/T, Western Union, L/C
Supply Ability 1 million per day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Product Name PVC Wire Conductor Tinned Copper
Insulation PVC Rated Temperature 105C
Rated Voltage 300V Standard UL758
Sizes 16-32AWG Color White Black Red Yellow Blue Black Brown
MOQ 1000meters Certificates UL Certification
Material PVC+Tinned Copper SIZE 2-30AWG
Packing 305/610m/roll Application Internal Wiring Electronic Equipment
High Light

UL PVC Insulated Copper Wire

,

610m/ Roll Insulated Copper Wire

,

105C Fire Resistant Wire
Leave a Message
Product Description

20 22 24 26AWG 300V 105C PVC Insulated Copper Wire UL1569 Fire Resistant Wire



Technical Data:

*Insulation:PVC

*Rated Voltage:300V

*Rated Temperature Range:105℃

*Insulation thickness:0.38mm

*Conductor:Tin-coated Copper Strand Wires



Characteristic:



PVC insulated material,excellent heat resistance and mechanical characters,easy stripping & cutting.

Resistance acids,alkalis,oils,moisture and mildew.



Product demension:

Conductor   Insulation Covering Jacket (mm) Max.Cond Resistance Unit length
Size
(AWG)		 Construction
(No./mm)		 Diameter
(mm)		   Nominal Thickness
(mm)		 Diameter
(mm)		 Thickness (mm) Diameter (mm) Thickness (Ω/KM) (M)(Ft)
30 7/0.10 0.30   0.4 1.1 0.40 1.9 0.78 381 610/2000
28 7/0.127 0.38   0.4 1.18 0.40 1.98 0.78 239 610/2000
26 7/0.16 0.5   0.4 1.3 0.40 2.1 0.78 150 610/2000
24 11/0.16 0.6   0.4 1.4 0.40 2.2 0.78 94.2 610/2000
22 17/0.16 0.76   0.4 1.56 0.40 2.36 0.78 59.4 610/2000
20 21/0.18 0.94   0.4 1.74 0.40 2.54 0.78 36.7 610/2000
18 34/0.18 1.19   0.4 1.99 0.40 2.79 0.78 23.2 305/1000
16 26/0.254 1.50   0.4 2.3 0.40 3.1 0.78 14.6 305/1000
14 41/0.254 1.89   0.78 3.45 0.78 5.01 0.78 8.78 305/1000
12 65/0.254 2.37   0.78 3.93 0.78 5.43 0.78 5.64 305/1000
10 105/0.254 3.02   0.78 4.58 0.78 6.14 0.78 3.55 305/1000
9 37/0.475 3.35   1.15 5.65 0.78 7.21 0.78 2.813 305/1000

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 0

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 1

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 2

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 3

OUT PRODUCTION

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 4

ABOUT US

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 5

610m/ Roll PVC Insulated Copper Wire UL1569 105C 20 22 24 26AWG 300V 6

Our company specializing in insulation wires and cables for 22 years,we’d like to introduce this item for you,and its further have silicone,(FEP,PFA)XLPE ,PVC,XLPVC s,High temperature insulation tubing wires and cable.Our products had adopted ISO9000,ISO14001,IATF16949 Quality System Authorities with UL.CUL ,CCC,VDE,CSA certificate.



Service

Packaging : Hard cardboard carton ( Customizable)

Shipment:
1. by express
2. by sea

3. by air plane

If you have your own shipper,you can tell me in advance.

My targert is to give my best serivce for you and hope we can have a good cooperation!


Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days





FAQ:



1, What’s the MOQ?

One roll. 100M/200M/300M/305M/500M/Roll.



2, How to get the samples?

We have most of the commonly used samples in Stock.

We can offer the free samples immediately.



3, What’s the payment terms?

LC, TT, Western Union, Money Gram and PayPal



4, What’s the delivery date?

Most of the commonly used products are in Stock. We can arrange it within one day.

We will arrange the delivery date as your requirement while the Bulk Production.



5, How to visit your factory/company?

We are located in Dongguan City, Guangdong Province, closed to Shenzhen,Guangzhou and Hong Kong. Only one and a half hours drive away. Convenient for visit.
