16AWG FT1 PVC Insulation Wire For Electronic Equipment Interial Wiring
Place of Origin | Guangdong,China |
---|---|
Brand Name | Mysun |
Model Number | UL1007 |
Minimum Order Quantity | 3050meters |
Price | 0.06~0.52USD per M |
Packaging Details | Standard packge: cardboard box Accept custom-made. |
Delivery Time | 7-15 working day |
Payment Terms | T/T, Western Union, MoneyGram |
Supply Ability | 500000 Meters per Day |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xCertification | ROHS/CCC/VDE/CCC/ISO9001:2008 | Conductor Type | Stranded |
---|---|---|---|
Color | Brown | Usage | Widely Used In Home Appliance ,lighting ,heater,motor & Generator,UAU,robot,industrial Power Etc |
Rated Voltage | 300v | Rated Temperature | 80C |
Size | 16AWG | Conductor | Tinned Copper |
Standard | UL758 | Insulation | PVC |
Type | Insulated | Max.Cond Resistance | 14.6 Ω/KM |
Construction | 26/0.254 | ||
High Light | 16AWG PVC Insulation Wire,FT1 PVC Insulation Wire,Interial Wiring Pvc Xlpe Cable |
PVC insulation wire 16AWG FT1 white color for interial wiring of electronic equipment
UL1007 Specifications:
Nominal voltage:600V
Temperature range: 125℃
Standard: UL1015
Insulation: PVC
Conductor: Tinner copper
Product features:
insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,
high voltage resistance, aging resistance, long service life and soft and easy to install.
Product Parameter
Applications:
* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.
Conductor | Insulation | Max.Cond Resistance | Unit length | |||
Size (AWG) |
Construction (No./mm) |
Diameter (mm) |
Nominal Thickness (mm) |
Diameter (mm) |
(Ω/KM) | (M)(Ft) |
32 | 7/0.08 | 0.24 | 0.38 | 1.00 | 542 | 610/2000 |
30 | 7/0.10 | 0.30 | 1.06 | 347 | ||
28 | 7/0.127 | 0.38 | 1.14 | 218 | ||
26 | 7/0.16 | 0.48 | 1.24 | 138 | ||
24 | 11/0.16 | 0.61 | 1.37 | 85.9 | 305/1000 | |
22 | 17/0.16 | 0.76 | 1.52 | 54.3 | ||
20 | 21/0.18 | 0.95 | 1.71 | 33.9 | ||
18 | 34/0.18 | 1.21 | 1.97 | 21.4 | ||
16 | 26/0.254 | 1.50 | 2.26 | 13.5 |
