High Temperature Silicone Wire 200c 1.5mm 30/0.25mm Tinned Copper Wires

Place of Origin Guangdong,China
Brand Name Mysun
Certification UL/cUL/CCC/CE/RoHS/SGS
Model Number UL3512
Minimum Order Quantity 3050meters
Price 0.06~0.325USD per M
Packaging Details Standard packge: cardboard box Accept custom-made.
Delivery Time 7-15 working day
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 500000 Meters per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Conductor Type Stranded Color Black
Usage Widely Used In Home Appliance ,lighting ,heater,motor & Generator,UAU,robot,industrial Power Etc Rated Voltage 300v
Rated Temperature 200C Size 1.5mm
Conductor Tinned Copper Certification ROHS/CCC/VDE/CCC/ISO9001:2008
Standard UL758 Insulation Silicone Rubber
Max.Cond Resistance 13.7Ω/KM Construction 30/0.25
High Light

Oil Resistance XLPE Insulation Wire

,

CCC High Temperature XLPE Wire

,

Tinned Copper Fiberglass Braided Wire

Leave a Message
Product Description

High Temperature Silicone Wire 200c 1.5mm 30/0.25mm Tinned Copper Wires



UL3512 Specifications:

Nominal voltage:600V

Temperature range: 200℃

Standard: UL3512

Insulation: Silicone Rubber

Conductor: Tinner copper



Insulation Color: Red/Balck/Yellow/Green/Bule/ Yellow&Green
Silicones rubber Insulated Tinner Cooper Silicone Wire
Tinned or bare, strand or solid copper conductor, 1.5 mm
Color-coded silicone rubber insulation
Uniform insulation thickness of wire to ensure easy stripping and cutting
Resistant to acid, alkali, oil, moisture and fungi, comforming ULstandard



Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.







Product Parameter



Applications:

* Widely used in lighting, household appliances, , lamps.
* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.


Conductor Insulation Max.Cond Resistance Unit length
Size
(AWG)
Construction
(No./mm)
Diameter
(mm)
Nominal Thickness
(mm)
Diameter
(mm)
(Ω/KM) (M)(Ft)
0.5 20/0.18 0.95 0.78 2.51 40.1 305/1000
0.75 30/0.18 1.17 2.73 26.7
1 40/0.18 1.3 2.86 20
1.25 50/0.18 1.5 3.06 14.35
1.5 30/0.25 1.6 3.16 13.7
2 41/0.254 1.85 3.41 8.78
2.5 50/0.25 2.06 3.62 7.16
3 60/0.25 2.3 3.86 6.5
4 56/0.30 2.62 4.18 4.7



Our Product



High Temperature Silicone Wire 200c 1.5mm 30/0.25mm Tinned Copper Wires 0



Product Description



High Temperature Silicone Wire 200c 1.5mm 30/0.25mm Tinned Copper Wires 1



High Temperature Silicone Wire 200c 1.5mm 30/0.25mm Tinned Copper Wires 2

Package & Delivery



Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days
