UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue

  • UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue
Place of Origin Guangdong，China
Brand Name Mysun
Certification UL/cUL/CCC/CE/RoHS/SGS
Model Number VDE
Minimum Order Quantity 305 meters
Price $0.02-0.32 Per Meter
Packaging Details Standard packge: cardboard box Accept custom-made.
Delivery Time 7-15 working day
Payment Terms T/T, Western Union, MoneyGram
Supply Ability 500000 Meters per Day

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Conductor Type Stranded Color Accept Customized
Usage Widely Used In Home Appliance ,lighting ,heater,motor & Generator,UAU,robot,industrial Power Etc Rated Voltage 450/750V
Rated Temperature 250C Size 2.5-0.34mm2
Conductor Nickel Plated Copper Wires Certification ROHS/CCC/VDE/CCC/ISO9001:2008
Standard UL758 Insulation FEP
Type Insulated Max.Cond Resistance 3.55-381 Ω/km
High Light

250C Feb Flexible Insulated Wire

,

UL758 Flexible Insulated Wire

,

24AWG Tinned Copper Insulated Wire
Leave a Message
Product Description

Specifications:

Nominal voltage:450/750V

Temperature range: 250℃

Standard: UL758

Insulation:PFA

Conductor: Nickel-Plated copper wires





Product features:

insulated wire has excellent resistance to high temperature, low temperature resistance, excellent electrical insulation performance,

high voltage resistance, aging resistance, long service life and soft and easy to install.



UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 0



Our Product





UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 1



Product Description



UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 2

Package & Delivery



Delivery:
Sample order: 1-3 working days
Big order: 5-10 working day
Customized order: 10-15 working days



UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 3



 Product Parameter



Conductor Insulation Max.cond Unit Length
resistance (m)(Ft)
Section Construction Diameter Nominal Thickness Diameter (Ω/km)
(mm²) (No./mm) (mm) (mm) (mm)
0.34 19/0.15 0.75 0.305 1.36 59.78 610/2000
0.5 19/0.19 0.95 1.56 40.1 305/1000
0.75 19/0.23 1.17 1.78 26.7
1 19/0.26 1.31 1.91 20
1.25 19/0.29 1.46 0.35 2.16 14.35
1.5 19/0.32 1.61 2.31 13.7
2 19/0.37 1.85 2.55 8.78
2.5 19/0.41 2.06 2.76 7.16


Applications:

* Widely used in lighting, household appliances, , lamps.

* electric appliances, instrumentation, motor wiring and electronics.
* gas appliances and other high-temperature environment.



UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 4





Company Introduction



Mysun Dongguan factory
Employee: 183
Area: 18000m²
Daily capacity: 2000,000m above



UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 5

UL758 250C Feb Flexible Insulated Wire 24AWG Color White Black Blue 6
